PETROLIMEX PLC SUPERTRANS INSULATING OIL
PLC SUPERTRANS is a high-quality electrical insulating oil, refined from premium mineral base oil through solvent and hydrogenation processes, then dehydrated and degassed under vacuum pressure to remove moisture and enhance dielectric properties. The product is nitrogen-treated to inhibit oxidation and contains antioxidant additives, delivering excellent cooling, insulating, and oxidation stability performance.
PRODUCT DETAILS
✅ Introduction to PLC SUPERTRANS
PLC SUPERTRANS is a high-quality electrical insulating oil, refined from premium mineral base oil through solvent and hydrogenation processes, then dehydrated and degassed under vacuum pressure to remove moisture and enhance dielectric properties. The product is nitrogen-treated to inhibit oxidation and contains antioxidant additives, delivering excellent cooling, insulating, and oxidation stability performance.
✅ Detailed Technical Specifications
| Parameter | Test Method | Standard Value | PLC SUPERTRANS Result |
|---|---|---|---|
| Color (max) | ASTM D1500 | 0.5 | 0.5 |
| Flash Point (°C, min) | ASTM D92 | 140 | 180 |
| Interfacial Tension at 25°C (dynes/cm) | ASTM D971 | ≥ 40 | 54 |
| Pour Point (°C, max) | ASTM D97 | -30 | -32 |
| Density at 15°C (g/cm³, max) | ASTM D1298 | 0.895 | 0.835 |
| Kinematic Viscosity @100°C (cSt, max) | ASTM D445 | 3.0 | 2.301 |
| Kinematic Viscosity @40°C (cSt, max) | ASTM D445 | 16.5 | 12.5 |
| Kinematic Viscosity @0°C (cSt, max) | ASTM D445 | 76.0 | 61.66 |
| Breakdown Voltage (kV, min) | ASTM D877 | 30 | 70 |
| Dielectric Loss @90°C (max) | ASTM D924 | 0.005 | 0.0015 |
| Water Content (ppm, max) | ASTM D1533 | 40 | 12 |
| Acid Number (mgKOH/g, max) | ASTM D974 | 0.03 | 0.0032 |
| Neutralization Number (mgKOH/g, max) | ASTM D974 | 0.28 | 0.135 |
| Corrosiveness | ASTM D1275/D130 | Non-corrosive | Non-corrosive |
| PCB Content (ppm) | ASTM D4059 | None | None |
✅ Key Advantages
-
High Insulating Performance: High breakdown voltage, low dielectric loss, ensuring safety for electrical equipment.
-
Excellent Oxidation Stability: Resistant to corrosion during long-term use, extending oil change intervals.
-
Efficient Cooling Capability: Superior heat dissipation and absorption, helping equipment operate stably.
-
Outstanding Physical Properties: Low viscosity at 40°C, low pour point, high flash point, and low volatility.
-
Safe and Environmentally Friendly: Free of hazardous substances such as PCB, low PCA content, ensuring safety for users and the environment.
✅ Applications
PLC SUPERTRANS is widely used in:
-
Power transmission and distribution transformers
-
Industrial transformers
-
Rectifiers, circuit breakers, switches
-
Circuit breakers, capacitors, and equipment requiring cooling and insulation
✅ Packaging and Storage
-
Packaging: 210-liter drums, 25-liter cans, 18-liter pails
-
Storage: Store in a covered warehouse, avoid direct sunlight or high temperatures (≥ 60°C). If stored outdoors, drums should be placed horizontally to prevent rainwater infiltration or loss of markings on the drum lids.
